S80 Threaded Ball Valve
| Manufacturer | Bray |
|---|
The Series S80 threaded ball valves have been designed to meet the needs of the chemical, textile and process industries. Standard two piece valve bodies are available in Stainless Steel. Stainless Steel bodies are investment cast and solution annealed for the highest quality and added strength. All body castings are marked with a foundry heat number for full traceability. These quarter turn valves feature a full port design that minimizes pressure drops with smooth flow characteristics.
ADDITIONAL INFORMATION
The Series S80 threaded ball valves have been designed to meet the needs of the chemical, textile and process industries. Standard two piece valve bodies are available in Stainless Steel. Stainless Steel bodies are investment cast and solution annealed for the highest quality and added strength. All body castings are marked with a foundry heat number for full traceability. These quarter turn valves feature a full port design that minimizes pressure drops with smooth flow characteristics.
Other features include low operating torque, adjustable stem packing, blowout proof stems, and stainless steel safety latch handles.
Testing
- All Series S80 valves comply with MSS-SP 72
- All valves are tested in accordance with MSS-SP 72
- Vacuum Service to 29 inches Hg gauge.
Size Range
¼ – 4″ (8 – 100mm)
Body Materials
ASTM A351 Gr CF8M
Temperature Range
-50°F to 450°F (-46°C to 232°C)
Stem Materials
ASTM A479 Type 316
Maximum Allowable Operating Pressure
1000 psi WOG (69 Bar)
Seat Materials
RPTFE
Shutoff Rating
Zero Leakage
Ball Materials
316SS
Body Style
Two Piece
Design Standard
MSS SP-110
End Connections
Threaded – NPT
Testing Standard
MSS-SP 72
Ports
Full Port
Face to Face
Manufacturers Standard
Applications
General Service, Air, Water, Oil & Gas
